E-Simpo 4Pin Light Socket Adapter, Gx24Q to E26/E27 Lamp Base

E-Simpo 4Pin Light Socket Adapter, Gx24Q to E26/E27 Lamp Base Converter. Need Re
Description Light Source Type LED Item model number GX24Q-E27 Style 12-Pack Are Batteries Included No Power Source AC, DC, Solar Number of Light Sources 1 Country of Origin China Warranty Description 100% work perfectly! You need remove the ballast inside the front head fixture! Batteries Included? No Batteries Required? No Finish Copper Plated Brand E-Simpo Material Polyester & Polyester Blend Is Discontinued By Manufacturer No Package Dimensions 8.1 x 4.7 x 1.6 inches Manufacturer E-Simpo Item Package Quantity 4 Bulb Base E26 Item Weight 11.2 ounces Special Features Not Dimmable Part Number GX24Q-E27 Color White Finish Type Copper Plated Wattage 100 watts Shape Round Voltage 120 Volts Shade Material Glass

This is 4P, NOT FOR 2P;Need BYPASS OR REMOVE the ballast, otherwise, it doesn't light on. G24q Series (Female Socket Fixture) to E26 (Male Bulb Base) Adapter - Q series has a shorter tip than D series and is more common in the US.

THE BALLAST IN YOUR FIXTURE MUST BE REMOVED OR BYPASSED FOR THESE ADAPTERS TO FUNCTION PROPERLY. CONSULT AN ELECTRICIAN IF YOU ARE UNSURE. DO NOT OPERATE A LED BULB WITH A BALLAST IN THE FIXTURE, DOING SO WILL LIKELY DAMAGE THE BULB.

All pin-based CFL, like GX24Q G24 GX23 G23 are lamp-ballast separated, but all screw-in E26 E27 are lamp-ballast integrated. ballast is a must to start a high voltage(600V-1500V 1ms) to light up the CFL, but it is dangerous for LED Lamp. Because LED Lamp are built with LEDs and Driver which is transforming the 100-240V AC to DC for LEDs. So the LED Driver input should be 100V-240V or 85-265V, so 600-1500V will be too high, and easily destroy the led lamp.

There are some LED Driver who can be compatible with the ballast, no LED Driver can be compatible with all the ballast. So the best thing is bypass or remove once we want to change CFL to LED Lamp. When we remove pin-based CFL, we only removed the lamp, the ballast is still working in front fixture; even we change to E26/E27 CFL, there will be 2 ballasts, the light will not work.

Product Description Short Version 15.5mm, 4P Conductive Gx24q to E26 Lamp base adapter Suitable for G24Q-1,G24Q-2,G24Q-3, GX24Q-1, GX24Q-2, GX24Q-3 Voltage Workable: 85-265V AC Max 75W Material: anti-burning PBT Housing, Copper Contact Works for 4-Pin CFL with : G24q-1: 10w 13w Quad Tube GX24q-1: 10w 13w Triple Tube G24q-2: 18w Quad Tube GX24q-2: 18w Triple Tube G24q-3: 26W 32w Quad Tube GX24q-3: 26w 32w Triple Tube
Allow You Install Standard E26/E27 Lamp into G24Q GX24Q Socket Please distinguish the pin base types: there are G24, 2P 4P, and G23, Gx23 etc. Check your old CFL lamp base so to confirm the existing fixture is G24q or Gx24q socket. If your socket is 2P, pls choose from G24d or G23 GX23 to E26/E27 Adapter below. No Ballast is Required. It is 100% that PL-C down light fixture has ballast inside. THROW AWAY the ballast before install the LED light, otherwise the ballast will make resonance high voltage which destroy the light, reviews like burnt, smell, hot, flicking are all results that not bypass the ballast correctly . Even you are replacing with E26/E27 CFL, you need remove the ballast also. Otherwise, the CFL E26/e27 Lamp will not work on.
How to bypass the ballast? 1.Turn Off the Power. 2. Find the Ballast. Usually it is embedded inside the ceiling fixture. Please pull off the existing PL lamp, reflector. Leave wire in junction box,find the ballast. 3. Normally, the Ballast has a black and white wire on the input side (AC input side,100-120V for North America). It also has two red and two blue output wires. To bypass this ballast, please cut all the Input and output wires, so total 6 wires cut. 4.Then you can connect the two red wires to the black wire. 5.Next, connect the two blue wires to the white wire. now ballast is bypassed Base Type 4-Pin G24Q GX24Q G24D 2-Pin in Diagonal G23 2Pin in Parallel GX23 2Pin in Parallel GX10Q 4-Pin Ballast Type Electronic Ballast Inductance Ballast Inductance Ballast Inductance Ballast Electronic Ballast Maximum Wattage 75W 75W 75W 75W 75W Work for CFL, Incandescent, LED CFL, Incandescent, LED CFL, Incandescent, LED CFL, Incandescent, LED CFL, Incandescent, LED
